FEATURES

RS POWER

This is much more than just a tweaked EP motor. Orbea's RD firmware offers the most natural, efficient pedaling experience possible.

RS WEIGHT

Rise is one of the lightest ebikes in its class. This increases range and also gives the most natural handling, a bike which rides a lot like your favorite trail rig.

RS INTERFACE

Slimming down bulky frames, integrating displays, removing cables and focusing on the frame aesthetics. Removing visual distractions leaves you free to focus on having the most fun possible.

RS RANGE

Orbea's 1.5x Factor means that thanks to lighter bikes, increased efficiency and grater reliance on your legs, battery life is extended by a factor of over 1.5. This means that their 540Wh battery is comparable to a 810Wh battery in a standard ebike system.

SPECIFICATIONS

FRAME

Orbea Rise Hydro 140mm travel 29" Boost 12x148

SHOCK
Fox Float DPS Performance 3-Position Evol custom tune 210x55mm
Optional Shock Configuration:
FOX FLOAT X PERFORMANCE 2-POS EVOL LV CUSTOM TUNE 210X55MM +($139)

FORK
Fox 34 Float Performance 140 3-Position QR15x110
Optional Fork Configuration:
FOX 36 FLOAT PERFORMANCE 150 GRIP 3-POSITION QR15X110 + ($105)

HEADSET
Acros Alloy 1-1/8 - 1-1/2" Integrated

CHAINRING
e*thirteen e*spec Direct Mount 32T Boost

CRANK
Shimano Steps EM600

SHIFTERS
Shimano SLX M7100 I-Spec EV

CASSETTE
Shimano CS-M7100 10-51t 12-Speed

REAR DERAILLEUR
Shimano XT M8100 SGS Shadow Plus

CHAIN
Shimano M6100

CHAINGUIDE
Orbea Rise chainguide

HANDLEBAR
OC Mountain Control MC31, Rise20, Width 800

STEM
OC Mountain Control MC20, 0º

BRAKES
Shimano M6120 Hydraulic Disc

ROTORS
180mm Front /180mm Rear

WHEELS
Race Face AR 30c Tubeless Ready
Optional Wheel Configurations
Option 1: RACE FACE NEXT-SL TLR IS +($419)
Option 2: OQUO MOUNTAIN CONTROL MC32TEAM IS BOOST +($420)

TYRES
Maxxis Dissector 2.40" 60 TPI 3CMaxxTerra Exo TLR
Optional Tyre Configurations
Option 1: MAXXIS REKON 2.60" 3C EXO TLR (F) / REKON 2.40" DUAL EXO TR +($0)
Option 2: MAXXIS MINION DHF 2.5" (F) / MINION DHR 2.4" (R) TLR +($20)
Option 3: MAXXIS ASSEGAI 2.50" DH TR(F) / MINION DHR II 2.40" DH TR(R) +($45)

TYRES
Maxxis Rekon 2.40" 120 TPI 3CMaxxTerra Exo+ TLR

FRONT WHEEL AXLE
N/A
Optional Front Wheel Axle:
Optional FOX KABOLT BOOST +($55)

SEATPOST
OC Mountain Control MC20, 31.6mm, Dropper
Optional Seatpost Configurations
Option 1: OC MOUNTAIN CONTROL MC20, 31.6MM, DROPPER, TRAVEL 125MM +($0)
Option 2: OC MOUNTAIN CONTROL MC20, 31.6MM, DROPPER, TRAVEL 150MM +($0)
Option 3: OC MOUNTAIN CONTROL MC20, 31.6MM, DROPPER, TRAVEL 170MM +($0)
Option 4: OC MOUNTAIN CONTROL MC20, 31.6MM, DROPPER, TRAVEL 200MM +($0)

SEATPOST LEVER
Shimano SL-MT500 I-Spec EV

SADDLE
Fizik Taiga S-alloy rail
Optional Saddle Configuration: FIZIK TAIGA KIUM RAIL +($55)

MOTOR
Shimano EP600-RS

BATTERY
Orbea Internal 540Wh (Optional 250 Wh Range Extender)
Optional Battery Configuration: 36V/10AH 360WH INTERNAL BATTERY -($150)

RANGE EXTENDER
N/A
Optional Range Extender Add-On: ORBEA CUSTOM RANGE EXTENDER 252WH +($529)

DISPLAY
N/A
Optional Display Add-On: SHIMANO EN600 CYCLE COMPUTER +($139)

CHARGER
Orbea 2.Generation eBike Smart charger 42V/2-4A

REMOTE
EN600-L
